Casement Window Parts & Hardware
Quiksash is our answer to obsolete aluminum and vinyl cladding materials no longer available for many brands of aluminum or vinyl clad wood window sash. With all original manufacturer's cladding obsolete or proprietary, replacement cladding is not available. Fenster solved this issue by engineering a replica window sash using our own cladding profiles that closely resemble practically any brand of roll-form clad window sash. We gave the same level of attention and detail to painted wood sashes to guarantee like, kind, quality, fit and function to the original sash when similar components are no longer available. Our painted wood sashes are guaranteed to perform at a much higher level than the original by deleting engineering flaws like boot glazing and exterior glazing stops. Choose from one of the re-engineered profiles already available (see model catalog) or contact us to inquire about getting your clad or primed wood sash replicated.
Need new hardware?
Standard Kit
(Universal casement hinge set)
$49.99
Deluxe Kit
(Hinges and operator)
$99.99
Jamb Seal
(Standard 5/16" vinyl bulb,
16-ft length per kit)
$15.99
Based on availability and as shown. Truth brand hardware only. Hardware is NOT sold separately. Please do not fill out a sash order form for hardware only. Please visit, www.windowpartsUSA.com for hardware sales.
Casement System
Casement replica sashes are engineered to maintain the fit and function of the original design with minimal change of appearance. Depending on the original specifications, our 1-1/2", 1-3/4" or 2" wide cladding is applied to match the original face width as closely as possible to include any deletion of exterior side glazing beads. This design change does affect the glass sizing, but does not affect the over-all net sash size, hence why we do not accept glass opening measurements.
- 1-1/2",1- 3/4" or 2" wide face
- Interior glass stop
- Perimeter weatherstrip applied where applicable
Specifications:
- Species: Clear pine treated with Woodlife 111 preservative.
- Finish: Stain grade: No visible knots greater than 1/16" within the sightline with window closed, minor knots may exist on edge views. Paint grade: Knots/imperfections may be filled/sanded smooth on any surface.
- Glass: LowE standard. Argon fill, HP-lowE, tempered, grills between the glass available options.
- Sizing tolerance: +/- 1/16” Sashes are undersized 1/16" for ease of fit.
- Measuring: Exact edge to edge of exterior surface. Glass sizes not accepted.
- Handing: Not required. Sashes are shipped with no hardware.
- Weatherstripping: Perimeter weatherstrip applied (where applicable)
- Shipping: UPS ground for small items under 48". Most orders are delivered via fenster truck.
- Warranty: 10 year full/+10 year pro-rated
A COMPLETED ORDER REQUEST IS REQUIRED FOR QUOTES. QUOTE REQUESTS ARE KEPT ON FILE FOR 10 BUSINESS DAYS. BY COMPLETING AN ORDER REQUEST YOU ARE NOT OBLIGATED TO PURCHASE UNTIL YOU HAVE GIVEN YOUR AUTHORIZATION TO BE INVOICED. CONTINUE TO SCROLL DOWN THIS PAGE TO CONTACT US FOR HELP.
Replica Clad Sashes
Fenster has several aluminum clad replacement sashes available in our Quiksash line of products. While these replica sashes are engineered to fit and operate in the original opening, most incorporate slight design alterations to accept our cladding, glazing method, and Fenster identification elements.
These sashes are nearly exact replicas of the original product with the exception of our standard glass stop for warranty identification purposes. Only standard Fenster cladding colors are available.
Replications available for:
- Biltbest
- Caradco
- Craftline
- MW
- Kolbe
- Norco
- Pozzi
- Malta
- Rockwell
- Sealrite
- SNE
- Windsor
Still need help? Send us an email to sales@fensterusa.com or give us a call at 844-973-4462 and we'll walk you through it.
